S No |
Dept |
Name of the Centre of Excellence |
Facility Available |
1 |
EEE |
BR Automation Lab |
- Power panel pp45 Touch screen resistive display
- X20BR9300 –Bus receiver
- X20DI9371 – Digital input Module
- X20Do9322 – Digital Output Module
- X20AI2622 –Analog Input Module
- X20AO2622- Analog output module
- X20AT2402 –Temperature input Module
- 8V1016.50 -2 Nos –Servo drive
- 8MSA2L.R0-67 -2Nos –Synchronous Motor
- 0PS05.1 -24V DC Power Supply
- 8CM002.12 – Motor cable
- 8CR002.12 – Resolver cable
|
2 |
NI LABVIEW ACADEMY |
- NI ELVIS PROTOTYPING BOARD -6 Nos
- DAQ Signal Accessory – 5 Nos.
- (Relay, Digital timer/counter, Analog input, Analog output, Digital input, Mic, Function generator, Temperature sensor – in DAQ card)
- NI 9263 – Voltage Output Module
- NI9225 – 24 bit 3 channel Voltage Input Module
- NI 9234 – Sound and Vibration Module
- NI 9512 – Motor Drive Interface Module
- NI 9205 – 16 bit 32 channel Voltage Input Module
- NI 9211 – Temperature Input Module
- NI 9516 – Servo motor drive interface Module
- NI 9219 – Multi range sensor module
- NI 9224 -24 Bit 8 channel Voltage Input Module
- NI 9401 – Digital Bi directional port
- NI CRIO 9074 – FPGA embedded controller
|
3 |
IT |
VMware |
Provides Supporting tool for Virtualization Student Projects are carried out. |
4 |
ECE |
Texas Instruments supported Embedded Laboratory |
It is equipped with world class Trainer Kits, Launch Pad, ARM Processor, Real time controllers to perform the training, research and development activities. |
5 |
VLSI Design Laboratory |
The VLSI DESIGN LAB is to expose the students and faculty to the circuit design of analog and digital circuit using Cadence Virtuoso tools. |
6 |
Communication Laboratory |
It involves system design and simulation exercises using MATLAB and Simulink and experiments based on hardware boards. |
7 |
Networks and Simulation Laboratory |
It is equipped with well-connected server and client structured systems to support the study of the concepts and protocols of networking and for the effective implementation of the routing protocols. |
8 |
MECH |
Centre for Composite Materials |
- Industrial Hot air oven
- Metallurgical Microscopes
- Electric Furnace
- Muffle Furnace (1000 °C)
- Universal Tensile Testing Machine with Double Shear Attachment (40 Ton Capacity)
- Torsion Testing Machine (60 Nm Capacity)
- Impact Testing Machine (300 Joules Capacity)
- Spring Testing Machine for Tensile and Compressive Load(50 KN)
- CNC Turning Machine
- CNC Milling Machine
- Arc/MIG/ TIG / Gas Welding Machine
- Double Disc Polishing Machine
- Profile Projector
- Brinell Cum Rockwell Hardness Testing Machine
- Injection Moulding Equipment
- Cannon Fenskee Viscometer
- Magnetic Stirrer with Hot Plate
- Pycnometer
- Vacuum Desiccator
- Seive shaker
- Surface Roughness Tester
- Micro Scribe
- Mounting box
|
9 |
Bio Fuels |
- Five Gas Analyser
- 4 Stroke Diesel Engine with electrical loading
- Multi Cylinder Petrol Engine
- 4 Stroke Diesel Engine with Hydraulic Loading
- Cleave Flash and Fire point apparatus
- Abels Flash and fire point Apparatus
- Asme Distillation Apparatus
- Aniline Point Apparatus
- Reid Vapour Pressure Test Apparatus
- Red Wood Viscometer
- Say Bolt Viscometer
- Smoke meter
|
10 |
AI&DS |
Computer Vision and IoT |
A Centre for Computer Vision is a field of Artificial Intelligence that trains computers to interpret and understand the visual world. Using digital images from cameras and videos and deep learning models, machines can accurately identify and classify objects — and then react to what they “see.” |
